The Merida Etmo 500 Pro Road Bike is a quality e-MTB featuring a powerful Bosch CX 100 Nm motor and high-capacity 800 Wh battery.
The Merida Etmo 500 Pro Road Bike is a quality e-MTB featuring a powerful Bosch CX 100 Nm motor and high-capacity 800 Wh battery.
Merida

Merida Etmo 500 Pro Road Bike in Gunmetal Grey/Black

£4,400.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Returns

ONLINE BIKE FIT PAYMENTS

You can cancel your bike fit appointment up to 48 hours prior to your bike fit and receive a full refund. Cancelling your appointment under 48 hours Velosport will not supply a full or partial refund, unless previously agreed by a member of staff.

You can change the date of your bike fit appointment up to 24 hours prior to your bike fit. Changing your appointment any later than 24 hours before your appointment you may be subject to a late amendment fee, or cancellation of your appointment without return of your payment or deposit unless previously agreed by a member of staff.

Customers that book and attend a frame sizing and afterwards by a bike from us will have the price of the frame sizing refunded at the point the bike is purchased.

CANCELLATION & RETURNS

For online orders if you are not completely satisfied with your purchase, you can return the items (excluding ridden bikes) to us in their as sold condition with packaging within 28 days of receipt.
We will issue a refund or exchange the item for a different size / colour if preferred. Delivery charges are only refundable where the goods are faulty.
Sorry, we cannot accept returns of books or software where any seals have been broken.
Please note :
The item is your responsibility until it reaches us. We recommend that you send the parcel using a delivery service that insures you for the value of the goods.
The cost of returning the item to us is your responsibility.
The parcel can take up to 7 working days to be processed once received.
The item(s) must be returned in its original packaging with all labels and tags and with all enclosed documentation.
We will be unable to accept the return of any item where there is evidence that these instructions have not been followed.
For large items such as bikes and wheels we reserve the right to charge a re-stocking fee of 10% to cover our administration costs.
Bikes must be returned in show room condition, and not ridden.
Faulty Item
If the item you received is faulty, please contact us with details of the product and the reason for return, and whether you require a refund or a replacement. We will then advise on how to proceed with the return. You have 30 days from receipt of the faulty item to notify us of your intent to return it and a further 30 days in which to do so.
Bike Returns

Once ridden, bikes cannot be returned.

If you are unsure of the correct size of bike, please contact us before placing your order.
Incorrect Item

If the item you received is not what you originally ordered, please contact us with details of the product and the reason for return, and whether you require a refund or a replacement. We will then advise on how to proceed with the return.
All refunds will be given as soon as possible, and usually take the form of a refund transaction onto the card used for the original purchase. At the very latest we will refund your money within 28 days from the day we receive your returned item. In the case of incorrect ordering and undisclosed reasons for return, a credit or exchange may be issued and the customer will be expected to pay the return postage costs.



For online orders you also have rights under The Consumer Contracts (Information, Cancellation and Additional Charges) Regulations 2013 CCR2014 which state that up to 14 days after receiving your goods, in most cases, you can change your mind and get a full refund. You have the right to cancel this contract within 14 days from delivery without giving any reason. This right does not apply to any customised or personalised goods bought through our website. To exercise this right please contact us prior to the expiry of the cancellation rights period. Please note ridden bikes cannot be returned or exchanged. Faulty bikes are subject to warranty

If you cancel this contract, we will reimburse to you all payments received from you, including the costs of delivery (except for the supplementary costs arising if you chose a type of delivery other than the least expensive type of standard delivery offered by us). Where charges apply, you are responsible for paying the return delivery charges.

We may make a deduction from the reimbursement for loss in value of any goods supplied, if the loss is the result of unnecessary handling by you.

We will make the reimbursement without undue delay, and not later than:

  • 14 days after the day we received back from you any goods supplied; or
  • (if earlier) 14 days after the day you provide evidence that you have returned the goods; or
  • if there were no goods supplied, 14 days after the day on which we are informed about your decision to cancel this contract.

We will make the reimbursement using the same means of payment as you used for the initial transaction, unless you have expressly agreed otherwise; in any event, you will not incur any fees as a result of the reimbursement.

The Consumer Rights Act 2015 says goods must be as described, fit for purpose and of satisfactory quality. During the expected lifespan of your product you're entitled to the following:

  • up to 30 days: if your goods are faulty, then you can get a refund;
  • up to six months: if they can't be repaired or replaced, then you're entitled to a full refund, in most cases;
  • up to six years: if the goods do not last a reasonable length of time, you may be entitled to some money back.
  • Bikes must be retured in show room condition.

This is a summary of some of your key rights. For detailed information from Citizens Advice please visitwww.citizensadvice.org.uk.

Customer Cancellations

Under the Consumer Contracts (Information, Cancellation & Additional Charges) Regulations you have the right to cancel your order for any item bought on this website for a full refund. This doesn’t apply to:

  • Goods made to the customer’s specification or are clearly personalised
  • Goods that are in clearance sales
  • Goods ordered that a subject to a restocking fee
  • Goods which are liable to deteriorate (nutrition) or expire rapidly (magazines)
  • Delivery fees where applicable

To cancel an order emailCustomer Service, call: 0.208.780,1978, or write to us at Velosport, 252 Upper Richmond Road, Putney, SW15 6TQ.

You can cancel anytime from placing your order up to the time you take possession of the goods (or in the case of a multiple order, the last part of the order).

Items should be returned with the original packaging and with any labels still attached and be in a new and unused condition. We are entitled to deduct an amount from the refund to reflect any loss in value of the goods supplied, if the loss is the result of unnecessary handling of the goods by you. We do not cover the costs of returning an item.

The Consumer Contract (Information, Cancellation and Additional Charges) Regulations do not apply to Financial and Insurance Services.

Velosport Cancellations

We reserve the right to cancel the contract between us if:

  • We have insufficient stock to deliver the goods you have ordered
  • The delivery service provider does not deliver to your area
  • One or more of the goods you ordered was listed at an incorrect price due to a typographical error or an error in the pricing information received by us from our suppliers; or
  • We have reason to suspect that there is a risk of a fraudulent transaction

If we do cancel your contract, we will notify you by email and will re-credit to your account any sum deducted by us (in respect of goods provided by us, and delivery services provided by the delivery service provider (unless amounts in respect of delivery are refunded directly by the delivery service provider), from your debit or credit card as soon as possible but in any event within 30 days of your order. We will not be obliged to offer any additional compensation for disappointment suffered.

Bike ordering is subject to a 20% handling charge which is non refundable.

We will charge a 20% handling fee for any bike refunds which are not down to a manufacturing fault.

Sale items cannot be purchased using finance.

ONLINE BIKE FIT PAYMENTS

You can cancel your bike fit appointment up to 48 hours prior to your bike fit and receive a full refund. Cancelling your appointment under 48 hours Velosport will not supply a full or partial refund, unless previously agreed by a member of staff.

You can change the date of your bike fit appointment up to 24 hours prior to your bike fit. Changing your appointment any later than 24 hours before your appointment you may be subject to a late amendment fee, or cancellation of your appointment without return of your payment or deposit unless previously agreed by a member of staff.

Customers that book and attend a frame sizing and afterwards by a bike from us will have the price of the frame sizing refunded at the point the bike is purchased.

Merida Etmo 500 Pro Road Bike in Gunmetal Grey/Black

Season:2026

Brand:Merida

Code:P-R936

A quality e-MTB means more runs, more fun, and more time just getting out there. The Merida Etmo 500 Pro Road Bike is Merida's most price-focussed Bosch-powered e-MTB.

Merida has used all their aluminium frame design and manufacturing know-how to create a durable frame inspired by the award-winning long-travel eONE-EIGHTY, but in an extra versatile and affordable package. This is backed up with a lifetime frame warranty for category 4 all mountain (AM) + enduro use. The Merida Etmo 500 Pro Road Bike features a powerful Bosch CX 100 Nm motor and high-capacity 800 Wh battery, paired with a reliable aluminium full-suspension frame.

Designed to be a serious off-road machine that won't break your budget, Suntour suspension units deliver on-trail performance, while the reliable shifts of the Shimano drivetrain and powerful SRAM brakes keep things under control. Fun but planted handling is achieved thanks to a mixed wheel size setup and a well-proven geometry concept. The Etmo uses 160 mm of travel at either end and mixed wheel sizes, so it’s fun and fast on any terrain, with handling that’ll bring a smile to the face of experienced riders and fresh faces alike.

Features:

  • Advanced LITE aluminium frame design with 140 mm travel
  • Mixed 29/27.5" size wheel setup for agile and confident handling
  • Bosch CX 100 Nm drive unit with 800 Wh internal battery
  • Suntour Zeron 36 X fork and Edge X rear shock, SRAM DB4 brakes and Shimano CUES 10-speed drivetrain
  • MERIDA COMP TRII tubeless ready wheelset and Maxxis tyres
  • Lifetime frame warranty for Category 4 All Mountain (AM) + Enduro use
Technical Information
  • Frame
    ETMO LITE
  • Material
    aluminium
  • Suspension travel
    142mm
  • Wheelsize
    27.5" x 2,6” max.
  • Axle standard
    148x12mm
  • Intube
    *
  • Frame size
    Short, Mid, Long, XLong
  • Color
    GUNMETAL GREY (BLACK)
  • Fork
    SR Suntour Zeron 36X
  • Fork type
    Air
  • Fork suspension travel
    140mm
  • Fork offset
    44mm
  • Max wheelsize
    29x2.6"
  • Shock
    SR Suntour Edge X
  • Brakes
    Sram DB4 stealth
  • Brake pistons
    4 piston
  • Rotors
    Sram CenterLine
  • Rotor size
    200mm
  • Headset
    FSA CRII NO.80
  • Handlebar
    MERIDA COMP TR II
  • Handlebar material
    aluminium
  • Handlebar width
    780mm
  • Handlebar rise
    35mm
  • Handlebar stem
    MERIDA EXPERT eTR II
  • Handlebar stem material
    aluminium
  • Handlebar stem diameter
    35mm
  • Stem angle
  • Stem mount
    Supernova mount
  • Stem length
    40 mm all sizes
  • Grip
    MERIDA COMP TR
  • Derailleur (r)
    Shimano Cues U6000 GS
  • Shifters
    Shimano MT500-L / Shimano Cues U6000-10
  • Seat post
    MERIDA EXPERT TR II
  • Seat post diameter
    34.9mm
  • Seat post setback
    0mm
  • Seat post travel
    125mm (XS), 150mm (S), 170mm (M), 200mm (L), 230mm (XL)
  • Seat clamp
    MERIDA EXPERT
  • Saddle
    MERIDA COMP SL
  • Saddle mount
    V-mount
  • Saddle accessory
    incl. MERIDA minitool
  • Pedal
    VP VPE-527
  • Chain
    Shimano LG500
  • Chainwheel
    FSA Direct Mount Steel Chainring
  • Chainring teeth
    36 teeth
  • Crank
    FSA CK-220 wide E-Bike Forged Crankset
  • Crank length
    160mm for all sizes
  • Freewheel
    Shimano Cues LG400
  • Freewheel range
    11-48 teeth
  • Freewheel speed
    10 speed
  • Hubs
    Shimano TC500-B / Shimano TC500-HM-B
  • Front hub width
    110x15mm
  • Spoke holes (Hub)
    32
  • Hub brake mount
    Centerlock
  • Rear hub width
    148x12mm
  • Rim
    MERIDA COMP TR II
  • Rim inner width
    28mm
  • Rim material
    aluminium
  • Rim compatibility
    Tubeless ready (tubeless tape and valves not included)
  • Rim size
    front 29", rear 27.5"
  • Tyre front
    Maxxis Minion DHF
  • Tyre front specification
    29x2.5", EXO wire, tubeless ready
  • Tyre rear
    Maxxis Dissector
  • Tyre rear specification
    27.5x2.4" wired, tubeless ready
  • Axles
    MERIDA EXPERT TR
  • Axle accessories
    including removeable lever, 6/4mm allen key
  • Spokes
    Black stainless
  • Spoke nipples
    black
  • Light front
    USB rechargable Chance Good CG-119PG-BLACK(1)
  • Light rear
    USB rechargable Chance Good CG-404RG-BLK
  • Fender
    RF-001 mini fender
  • Drive unit
    Bosch Performance Line CX
  • Battery
    Bosch PowerTube 800
  • Battery capacity
    800Wh
  • Battery lock
    Abus Key
  • Display
    Bosch Purion 200
  • Max. weight
    140 kg
  • Geometry Tyre Sizes
    29/27.5" for all sizes
  • ST seat tube [mm]
    Short: 380, Mid: 405, Long: 430, XLong: 455
  • TT top tube [mm]
    Short: 556, Mid: 584, Long: 609, XLong: 636
  • CS chain stay length [mm]
    446 for all sizes
  • HTA head tube angle [°]
    65 for all sizes
  • STA seat tube angle [°]
    78.5 for all sizes
  • BD bottom bracket drop [mm]
    20 for all sizes
  • HT head tube [mm]
    Short: 105, Mid: 115, Long: 115, XLong: 125
  • FL fork length [mm]
    580 for all sizes
  • FO fork offset [mm]
    44 for all sizes
  • R reach [mm]
    Short: 425, Mid: 450, Long: 475, XLong: 500
  • S stack [mm]
    Short: 644, Mid: 653, Long: 653, XLong: 662
  • WB wheel base [mm]
    Short: 1202, Mid: 1231, Long: 1256, XLong: 1285
  • SH stand over height [mm]
    Short: 745, Mid: 748, Long: 751, XLong: 754
  • Spare Parts (Frame)
    AM0, AM7, AM8
  • Spare Part No. 1
    Item-No: A2300000696, Name: BOLT, Info: M6x1 OD15/17mm L74mm, Pieces: 1
  • Spare Part No. 2
    Item-No: A2221000040, Name: BEARING, Info: 172607V-2RS OD26mm ID17mm W7mm, Pieces: 1
  • Spare Part No. 3
    Item-No: A2294000102, Name: WASHER, Info: OD21mm ID17.1mm H3mm, Pieces: 1
  • Spare Part No. 4
    Item-No: A2294000016, Name: WASHER, Info: OD19mm ID15.1mm H3mm, Pieces: 3
  • Spare Part No. 5
    Item-No: A2221000043, Name: BEARING, Info: 3802V-2RS OD24mm ID15mm W7mm, Pieces: 3
  • Spare Part No. 6
    Item-No: A2300000609, Name: SCREW, Info: M10x1 L15mm, Pieces: 1, Torque NM: 15~17
  • Spare Part No. 7
    Item-No: A2300000625, Name: BOLT, Info: M6x1 OD10mm L39mm, Pieces: 1
  • Spare Part No. 8
    Item-No: A2298000113, Name: SCREW, Info: M6x1 L16mm, Pieces: 4, Torque NM: 8~10
  • Spare Part No. 9
    Item-No: A2294000196, Name: WASHER, Info: for M6 sunkenhead screw OD16mm, Pieces: 4
  • Spare Part No. 10
    Item-No: A2300000693, Name: BOLT, Info: M6x1 OD12mm L62mm, Pieces: 1
  • Spare Part No. 11
    Item-No: A2300000803, Name: SCREW, Info: M8x1 L49mm, Pieces: 1, Torque NM: 18~20
  • Spare Part No. 12
    Item-No: A2294000224, Name: LOCK RING, Info: for ID21, Pieces: 1
  • Spare Part No. 13
    Item-No: A2294000223, Name: WASHER, Info: OD15.5mm ID12.1mm H3mm, Pieces: 2
  • Spare Part No. 14
    Item-No: A2221000035, Name: BEARING, Info: 6801V-2RS OD21mm ID12mm W5mm, Pieces: 2
  • Spare Part No. 15
    Item-No: A2031000094, Name: LINK, Pieces: 1
  • Spare Part No. 16
    Item-No: A2262000059, Name: WASHER, Info: OD15.5mm ID12.1mm H31mm, Pieces: 1
  • Spare Part No. 17
    Item-No: A2300000743, Name: SCREW, Info: M15x1 L20.5mm, Pieces: 2, Torque NM: 23~25
  • Spare Part No. 18
    Item-No: A2294000225, Name: LOCK RING, Info: for ID24, Pieces: 2
  • Spare Part No. 19
    Item-No: A2300000652, Name: BOLT, Info: M6x1 OD10mm L18.8mm, Pieces: 2
  • Spare Part No. 20
    Item-No: A2294000212, Name: WASHER, Info: OD14mm ID10.1mm H3.1mm, Pieces: 4
  • Spare Part No. 21
    Item-No: A2294000211, Name: LOCK RING, Info: for ID22, Pieces: 2
  • Spare Part No. 22
    Item-No: A2221000060, Name: BEARING, Info: 6900V-2RS OD22mm ID10mm W6mm, Pieces: 2
  • Spare Part No. 23
    Item-No: A2292000141, Name: WASHER, Info: OD13mm ID9mm H1mm, Pieces: 1
  • Spare Part Headset No. 1
    Item-No: A2191000301, Name: HEAD SET, Info: FSA ZS56/ZS66 Cable through Headset, Pieces: 1
  • Spare Part Headset No. 2
    Item-No: A2298000160, Name: SCREW, Info: M4x0.7 L10mm, Pieces: 8, Torque NM: 3~5
  • Spare Part Headset No. 3a
    Item-No: A2263000069, Name: BLIND PLUG, Info: for top tube opening, Pieces: 1
  • Spare Part Headset No. 3b
    Item-No: A9098000029, Name: BOSCH OEM PART, Info: Bosch BRC 3100, Pieces: 1, Torque NM: 3~5
  • Spare Part Headset No. 4
    Item-No: A2298000144, Name: SCREW, Info: M5x0.8 L10mm, Pieces: 4, Torque NM: 4~6
  • Spare Part Headset No. 5
    Item-No: A2143000203, Name: BUSHING, Info: For Screwhole, Pieces: 1
  • Spare Part Headset No. 6.1
    Item-No: A2263000102, Name: COVER, Info: for battery (800Wh), Pieces: 1
  • Spare Part Headset No. 6.2
    Item-No: A2263000067, Name: COVER, Info: for battery, Pieces: 1
  • Spare Part Headset No. 7
    Item-No: A2300000318, Name: SCREW, Info: M4x0.7 L12mm, Pieces: 4, Torque NM: 3~5
  • Spare Part Headset No. 8
    Item-No: A2263000070, Name: COVER MOUNT, Info: Fidlock Pinlock vertical Female, Pieces: 1
  • Spare Part Headset No. 9
    Item-No: A2030000033, Name: MOUNT, Pieces: 1
  • Spare Part Headset No. 10
    Item-No: A2263000081, Name: COVER MOUNT, Info: Fidlock Pinlock vertical Male, Pieces: 1
  • Spare Part Headset No. 11
    Item-No: A2232000064, Name: CHAIN GUIDE, Info: for Bosch with 55mm chainline, Pieces: 1
  • Spare Part Headset No. 12
    Item-No: A2263000103, Name: PROTECTOR, Info: For motor (Bosch CX/PX/PL), Pieces: 1
  • Spare Part Headset No. 13
    Item-No: A2263000104, Name: COVER, Info: Extra Cover for Bosch PX/PL Motor, Pieces: 1
  • Spare Part Headset No. 14
    Item-No: A2298000361, Name: SCREW, Info: M4x0.7 L12mm, Pieces: 3, Torque NM: 3~5
  • Spare Part Headset No. 15
    Item-No: A2292000139, Name: WASHER, Info: OD11mm ID4.5mm H0.8mm, Pieces: 1
  • Spare Part Headset No. 16
    Item-No: A2158000094, Name: PROTECTOR, Info: for chain stay, Pieces: 1
  • Spare Part Headset No. 17
    Item-No: A2002000135, Name: THRU AXLE, Info: EXPERT TR; L=178.5mm M12x1 TL=13.5mm, Pieces: 1
  • Spare Part Headset No. 18
    Item-No: A2298000409, Name: SCREW, Info: M6x1 L12mm, Pieces: 3, Torque NM: 12~14
  • Spare Part Headset No. 19
    Item-No: A2136000158, Name: MOUNT, Info: PM200, Pieces: 1
  • Spare Part Headset No. 20
    Item-No: A2116000284, Name: FENDER, Info: Small Fender, Pieces: 1
  • Spare Part Headset No. 21
    Item-No: A2263000062, Name: MOUNT, Info: for charging port, Pieces: 1
  • Spare Part Headset No. 22
    Item-No: A2143000082, Name: CABLE GUIDE, Info: for mechanical RD cable, Pieces: 1
  • Spare Part Headset No. 23
    Item-No: A2258000099, Name: CABLE GUIDE, Info: for brake and speed sensor/light, Pieces: 1
  • Spare Part Headset No. 24
    Item-No: A9085000045, Name: BOSCH OEM PART, Info: Bosch PT600/800 battery rail, Pieces: 1
  • Spare Part Headset No. 25
    Item-No: A2158000117, Name: PROTECTOR, Info: for cables in head tube, Pieces: 1
  • Spare Part Headset No. 26
    Item-No: A2302000117, Name: NUT, Info: M5 - For battery rail, Pieces: 2
  • Spare Part Headset No. 27
    Item-No: A2302000116, Name: NUT, Info: for Bosch Motor Mount, Pieces: 2
  • Spare Part Headset No. 28
    Item-No: A2143000199, Name: CABLE PLUG, Pieces: 1
  • Spare Part Headset No. 29
    Item-No: A2298000178, Name: SCREW, Info: M5x0.8 L8mm, Pieces: 1, Torque NM: 6~8
  • Spare Part Headset No. 30
    Item-No: A2262000071, Name: BOSCH OEM PART, Info: Sleeve Narrow, Pieces: 2
  • Spare Part Headset No. 31
    Item-No: A2300000765, Name: BOSCH OEM PART, Info: Bolt Narrow, Pieces: 2, Torque NM: 30
  • Spare Part Headset No. 32
    Item-No: A2258000286, Name: CABLE GUIDE, Info: Stick on cable guide (3/4/4 mm), Pieces: 3
  • Spare Part Headset No. 33
    Item-No: A2258000287, Name: CABLE GUIDE, Info: Stick on cable guide (4/5 mm), Pieces: 2
  • Spare Part Fender No. 1
    Item-No: A2115000037, Name: FENDER, Info: Front Fender, Pieces: 1
  • Spare Part Fender No. 2.1
    Item-No: A2117000082, Name: FENDER ACCESSOIRES, Info: Front Fender Strut for XFUSION MIGO 34 fork, Pieces: 1
  • Spare Part Fender No. 2.2
    Item-No: A2117000029, Name: FENDER ACCESSOIRES, Info: Front Fender Strut for SUNTOUR ZERON 36X fork fork, Pieces: 1
  • Spare Part Fender No. 3
    Item-No: A2298000144, Name: SCREW, Info: M5x0.8 L10mm, Pieces: 1
  • Spare Part Fender No. 4
    Item-No: A2302000027, Name: NUT, Info: M5, Pieces: 4
  • Spare Part Fender No. 5
    Item-No: A2298000068, Name: SCREW, Info: M5x0.8 L10mm, Pieces: 4
  • Spare Part Fender No. 6
    Item-No: A2119000001, Name: FENDER ACCESSOIRES, Info: Fork Adapter Suntour, Pieces: 1
  • Spare Part Fender No. 7
    Item-No: A2292000049, Name: WASHER, Info: OD10mm ID5.5mm H1mm, Pieces: 3
  • Spare Part Fender No. 8
    Item-No: A2116000283, Name: FENDER, Info: Long Performance Fender, Pieces: 1
  • Spare Part Fender No. 9
    Item-No: A2298000379, Name: SCREW, Info: M5x0.8 L35mm, Pieces: 2
  • Spare Part Fender No. 10
    Item-No: A2298000250, Name: SCREW, Info: M4x0.7 L12mm, Pieces: 2
  • Spare Part Fender No. 11
    Item-No: A2098000052, Name: CARRIER, Info: for eONE-FORTY LITE only with fender and screws, Pieces: 1
  • Spare Part Fender No. 12
    Item-No: A2298000473, Name: SCREW, Info: M5x0.8 L33mm, Pieces: 2
  • Spare Part Fender No. 13.1
    Item-No: A2292000014, Name: WASHER, Info: OD9mm ID5.2mm H5mm, Pieces: 6
  • Spare Part Fender No. 13.2
    Item-No: A2292000028, Name: WASHER, Info: OD9mm ID5.2mm H3mm, Pieces: 2
  • Spare Part Fender No. 14.1
    Item-No: A2101000053, Name: FENDER, Info: Rear Fender Inside Strut, Pieces: 1
  • Spare Part Fender No. 14.2
    Item-No: A2116000358, Name: FENDER, Info: Rear Fender, Pieces: 1
  • Spare Part Fender No. 15
    Item-No: A2298000430, Name: SCREW, Info: M5x0.8 L10mm, Pieces: 1
  • Spare Part Fender No. 16
    Item-No: A2298000240, Name: SCREW, Info: M6x1 L16mm, Pieces: 1
  • Spare Part Fender No. 17
    Item-No: A2302000016, Name: NUT, Info: M5, Pieces: 1
  • Spare Part Fender No. 18
    Item-No: A2298000239, Name: SCREW, Info: M6x1 L14mm, Pieces: 2
  • Spare Part Fender No. 19
    Item-No: A2298000237, Name: SCREW, Info: M6x1 L20mm, Pieces: 2
  • Spare Part Fender No. 20
    Item-No: A2184000060, Name: KICKSTAND, Info: for rear mount, Pieces: 1
  • Spare Part Fender No. 21
    Item-No: A2292000005, Name: WASHER, Info: OD10mm ID6.2mm H1mm, Pieces: 1
Sizing Information
Professional Opinion
Product Reviews
Write a review
0 As rated by 0 customers

Write a review for Merida Etmo 500 Pro Road Bike in Gunmetal Grey/Black

Your name
Your email address
How would you rate it?
Would you recommend this product?
Let others know your opinion
Submit Review Close
Question(s) answered about Merida Etmo 500 Pro Road Bike in Gunmetal Grey/Black
Ask a question
Question(s) asked regarding Merida Etmo 500 Pro Road Bike in Gunmetal Grey/Black

Ask a question

Your name
Your email address
Your phone number
Your question
Submit Question  Close
Home Mountain Biking Bikes Merida Electric Bikes
